氣體輔助注塑技術原理

Principle of gas assisted injection molding technology

氣體輔助注塑成型技術應用已有幾十年的歷史，其原理是高壓氮?dú)馍淙胨芰?a title='產品' target='_blank' href='http://www.8818851.com' class='seolabel'>產品內部，使塑料產品內部產生中空截面，利用高壓氮?dú)獯孀⑺軝C(jī)的高壓注射及保壓，使塑料產品內部向外部試壓，是塑料產品表面緊靠模具表面，消除塑料產品的縮痕及塑料產品冷卻所產生應力，使塑料產品不變形及表面缺陷，完成塑料產品注塑的全部過程。

Gas-assisted injection molding technology has been applied for decades. Its principle is that high-pressure nitrogen is injected into plastic products, so that hollow sections are generated inside plastic products. High-pressure nitrogen is used to replace the high-pressure injection and pressure preservation of injection molding machine, so that the internal pressure test of plastic products is external. Eliminate the shrinkage of plastic products and plastic products cooling stress, so that plastic products do not deformation and surface defects, complete the whole process of plastic products injection.

氣體輔助注塑工藝圖示：

第一階段：塑料注塑：溶體進去型腔，遇到溫度較低的模壁，形成一個較薄的凝固層。

第二階段：氣體射入：氮?dú)膺M(jìn)入熔融的塑料，推動中心未凝固的塑料進入尚未充滿的型腔。

第三階段：氣體射入結束：氣體繼續推動塑料溶體流動直至到溶體充滿整個型腔。

第四階段：氣體保壓：在冷卻過程中，氣道中的氣體壓縮溶體，進行氣體保壓，確保制件的外觀及強度。

第五階段：氣體排出：在模具開模前，氣體從制件內部排出，氣壓降至到常壓下。

氣體輔助注塑優點：

1、簡化產品模具繁瑣設計，能夠注塑成型壁厚較大產品；

2、減輕產品重量，節約原材料最高可達50%；

3、加快冷卻速度，縮短產品生產周期；

4、可解決和消除產品表面縮痕問題；

5、減少產品內應力和翹曲變形，使產品尺寸更加穩定；

6、通過有氣道的加強筋，提高產品強度而不增加產品重量；

7、較低模腔內壓力，減少模具損耗；

8、降低注塑機鎖模壓力，延長注塑機壽命。

Advantages of gas assisted injection molding:

1, simplify the tedious design of product mold, can be injection molding products with larger wall thickness;

2. Reduce product weight and save up to 50% of raw materials;

3, accelerate the cooling speed, shorten the production cycle;

4, can solve and eliminate product surface shrinkage marks;

5, reduce the internal stress and warping deformation of the product, so that the product size is more stable;

6, through the airway reinforcement, improve the strength of the product without increasing the weight of the product;

7. Lower pressure in die cavity to reduce die loss;

8, reduce the injection molding machine clamping pressure, prolong the life of the injection molding machine.
